25.2km / Reel FRP Rod Strength Member Low Elongation
Features:
* High tensile strength, high modulus, low thermal conductivity, low elongation, low expansion, and wide temperature range;
* Non-metallic materials are not sensitive to electric shock, and are suitable for areas with multiple lightning and rainy weather conditions;
* Chemical resistance, compared with the metal core, the GFRP reinforcing core does not affect the fiber transmission index
* The fiber optic cable using the GFRP reinforcing core can be installed next to the power line and the power supply device, and is not interfered by the induced current generated by the power line
* Smooth surface, stable size, easy to process and lay, and the application range is wide.
| Property | Values |
| Tensile strength (Mpa) | ≥1500 |
| Tensile modulus(Gpa) | ≥50 |
| Flexural strength(Mpa) | ≥1100 |
| Flexural modulus(Gpa) | ≥50 |
| Elongation at break (%) | ≤4 |
| Coefficient of linear thermal expansion(-30-80℃)(1/℃) | ＜8*10-6 |
| Diameter tolerance (mm) | ±2% |
| Minimum bending radius(mm) | 40*D |
| Density (g/cm3) | 2.05-2.15 |
| High temperature bending test(50D,100℃,120h) | No bur, crack and break |
| Low temperature bending test(50D,-40℃,120h) | No bur, crack and break |
| Torsion (±360°/m) | Not disintegrated |
FRP stength member (FRP Rod) is a new type of high-performance engineering composite material prepared by pultrusion process with resin as the matrix material and glass fiber as the reinforcing material.It is a new type of high performance non-metallic cable reinforcement.
FRP strength member overcomes the defects of traditional metal cable reinforcements, has excellent corrosion resistance, lightning resistance, electromagnetic field interference resistance, high tensile strength, light weight, environmental protection, energy saving, etc., and is widely used in a variety of fiber optic cable.
Product Description
Fiber optical cable with FRP strength member 1/2/4 core single mode ftth drop wire cable
Most of the optical cables are single-core and double-core structures, and can also be made into a four-core structure. The cross-section is an 8-shaped cross-section. The reinforcement is located at the center of the two circles. The metal or non-metallic structure can be used. The optical fiber is located at the geometric center of the 8-shaped geometry. . G.657 small bending radius optical fiber is used for the optical fiber in the sheathed cable, which can be laid with a bending radius of 20mm, which is suitable for entering the house in the building by means of pipes or bum lines.
Application
1. Used for indoor wiring, directly used by end users;
2. Used for building optical fiber cables;
3. For indoor wiring of users in FTTH.
FAQ
1. About the price?
Re. We usually quote within 12 hours after we confirm the technical data of your products.
2. What's the payment method?
Re.We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.
3. What are your terms of payment?
Re.30% in advance,and 70% before shipment
4. How to ship the items to me?
Re.Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.
5. How long is your delivery time?
Re.The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
